Extended Wheelbase Skid Steer Loader Narrow Space Operation With Bucket

Basic Information
Place of Origin: Made in China
Brand Name: M&D
Certification: CE,ISO
Model Number: JC60M
Minimum Order Quantity: 1
Price: Negotiated
Packaging Details: Export Standard Package
Delivery Time: 3-20days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500Units/Month
Detail Information
Product Name: New Hydraulic Pump Mini Electric Skid Steer Loader With Bucket Machine Weight: 2800kg
Warranty: One Year Bucket Capacity: 850kg
Max Travel Speed: 8km/h Operating Weight: 3200kg
Tipping Load: 1700kg Height To Bucket Hinge Pin: 2920mm
High Light:

forklift truck side loader


side lift forklift trucks


extended wheelbase skid steer loader

Product Description

Product Description
New Hydraulic Pump Mini Electric Skid Steer Loader With Bucket
Compact structure,maneuverable movement suitable for narrow space operation
Close cabin with joystick control system
Extended wheelbase
Double accelerograph control
Auto-leveling system
Multi-function with a wide range of attachments
Hydraulic brake



Extended Wheelbase Skid Steer Loader Narrow Space Operation With Bucket 0Extended Wheelbase Skid Steer Loader Narrow Space Operation With Bucket 1


Rated Operating Capacity 850
Tipping load(Kg) 1700
Bucket Capacity(m3) 0.4-0.5
Lifting Force(Kg) 2000
Hydraulic Pump Flow(L/min) 75
Engine power(HP) 65
Weight(Kg) 3000
Max.Travel Speed (km/h) 12
Grade ability(º) 20
Tire 12-16.5
Fuel/hyd.oil capacity(L) 80/80
Height at Maximum Extension 3690mm
Hinge Pin Height 2920mm
Total Height 2050mm
Length with Bucket 3440mm
Length without Bucket 2780mm
Width with Bucket 1820mm
Track Width 1500mm
Wheelbase 1085mm
Ground Clearance 200mm
Dumping Angle 40°
Dumping Height 2330mm
Maximum Reach 710mm


Maker/Model: XINCHAI 490

Net power:60hp/2650rpm

Type:4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine

Displacement(L) 2.54



Open-type operator cab

Hand control system(Mechanical type)

Standard bucket

Auxiliary hydraulic couplers



Enclosed operator cab with A/C

Cab fitted with a heater as standard

Hydraulic joystick controls


Backhoe,Breaker,Angle blade,Auger,Sweeper,Pallet fork,

Combinition bucket,Mower,Asphalt cutter,and More


Packaging & Shipping

Export Standard Package


Service and Delivery

We offer 24 hour service including Pre sales service and after sales. service.Professional engineer will develop personalized solutions according to your need.

Package can be customized. We will protect the product very well by wood case and bubble film.

We usually use the ocean shipping.


Company Information

Shanghai M.Touch Road Mechanical Equipment Co,Ltd has a professional team with 17 years rich experience in forklift industry sales and service , and the team have ever serviced in famous multiple national companies such as Jungheiinrich, Linde, Hyster, and Toyota etc in the forklift industry.



30% by T/T in advance, 70% before shipment.

L/C at sight

If there are some info. we didn't show it, please check our website or if you would like leave a message, it would be a great honor for us.

Why choose us?

M&D is committed to offer not only products with high quality and performance and competitive price, but also in-time delivery and comprehensive 7/24 after-sale services.

What is the product range of our factory?

M&D is a large-scale machinery manufacturing enterprise primarily specializes in supplying wheel loaders, forklift trucks,Warehousing equipment, port equipment and related attachments. We can also customize non-standard products according to customer's requirements.

What certificates do you have?

All products meet with the ISO 9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
