Battery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse Forklift

Battery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse Forklift

    • Battery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse Forklift
    • Battery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse Forklift
    • Battery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse Forklift
  • Battery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse Forklift

    Product Details:

    Place of Origin: china
    Brand Name: M&D
    Certification: CE ISO
    Model Number: FB-45

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiable
    Packaging Details: nude
    Delivery Time: 15-20 days
    Supply Ability: 200set per month
    Contact Now
    Detailed Product Description
    Max Lift Height: 4011mm Tyre: Pneumatic Tires Solid Tires
    Color: Customised Warrant: 1 Year
    Battery: 80/500V/AH

    A series 4.0-5.0 ton four wheel battery fast charged zero emission low noise no corrosion electric forklift

    Selling Point



    • Chinese Automatic Transmission With TCM Technology Improves Operator's Efficiency, Responding Rapidly And Smoothly.
    • Intelligent Buffer Design Avoids Sharp Collision And Minimizes The Risk Of Damage During Lower Of Loads, Wide-view Mast Also Provides High-visibility To The Operator
    • High-Capacity Aluminum Radiator Is Designed For Efficient Thermal Transfer Fin And Oil Cooler For The Transmission Torque Converter, Assists In Improving Iongevity Of Engines.
    • Wide Range Of Diesel, Gasoline, And LPG Engine Options.



    STABILITY

    ● The internationally advanced parallel arrangement is adopted for traction motor, and the machine is characterized by sinking type designed battery layout, resulting in lower gravity center and better stability of entire truck.

    ● Flexible steering system, with smaller turning radius, allows turnaround within confined passageway.

    COMFORT

    ● The adjustable, small-diameter steering wheel with tilt designed based on ergonomics offers good hand feeling, and the seat can also be adjusted forward and backward, which can provide best driving position for the operator.

    ● Easy to see display is located to overhead, increase visibility and operability, thus with higher driving safety.

    ● Featured with low noise, energy saving and no exhaust emission, all the performances of this vehicle meet the requirement of eco-friendliness.

    RELIABILITY&SAFETY

    ● Famous brand controllers, connectors, battery plug, emergency switch and dashboard are applied so as to ensure the reliability of the performance and easy operation.

    ● Major parts such as chassis, drive axle, steering axle, and mast are all designed with high strength to satisfy high-strength work conditions.

    ● Emergency switch is in standard specification which meets the Euro safety regulation.

    ● Besides, there’s overloading protection for electronics and hydraulic system.

    ADVANCED

    ● EPB (Electronic Parking Brake), which realizes intelligent parking brake, with lower labor intensity of the operator, and higher safety.

    ● Soft landing system.

    ● Full AC configuration includes AC traction motor + AC pump motor; with higher performance of entire truck, and longer battery life.

    MAINTENANCE

    ● The fully opened battery cover makes the battery service rather easy and the cover of the controller can be easily opened.

    ● The brushless, maintenance-free AC drive motor reduces operation cost significantly.

    ● The option of side roll out battery is very convenient for fast, efficient, and safe, and is suitable for continuous work conditions.

    Basic Info

    Model No.: FB45

    Power Type: Electric

    Load Center: 500mm

    Front Overhang: 555mm

    Turning Radius: 2755mm

    Min. Insecting Aisle: 2955mm

    Max. Gradeability: 15%

    Wheelbase: 2000mm

    Additional Info

    Packaging: Nude Packing

    Productivity: 10000 Per Year

    Transportation: Ocean

    Place of Origin: China

    Supply Ability: 10000 Per Year

    Certificate: ISO 9001;ISO 14001

    HS Code: 84271090

    Product Description

    4.5 Ton Electric Forklift

    4.5 Ton forklift with side out battery advantages:
    Automatic slowing down function when steering enhance truck safety.
    Hydraulic load sensing steering technology ,flexible and reliable.
    AC system
    IP54 protection degree of AC motor.
    Hydraulic emergency brake device enhance truck travelling safety.
    Forklift with side out battery(two way,From top and from side),it's more easy for repair and maintain.
    Curtis or Zapi AC controller
    Famous brand battery and charger
    Reasonable structure,better heat dissipation for controller
    Battery water automatic replenish for optional
    Powerful AC driving motor applied to reduce maintenance cost and increase the overall performance.





    General
    Model   FB45 FB50 FB60
    Power Type   Electric Electric Electric
    Load Capacity kg 4500 5000 6000
    Load centre mm 500 500 500
    Tyre
    Tyre     Pneumatic Tyre Pneumatic Tyre Pneumatic Tyre
    Front Tyre   28×12.5-15-24PR 28×12.5-15-24PR 28×12.5-15-24PR
    Rear Tyre   7.00-12-12PR 7.00-12-12PR 7.00-12-12PR
    Overall Dimension
    Lift Height mm 3000 3000 3000
    Fork Size L×W×T mm 1070×150×50 1070×150×50 1070×150×50
    Mast Tilt Angle F/R . 6/9 6/9 6/9
    Mast Lowered Height mm 2330 2330 2330
    Mast Extended Height(with backrest) mm 4165 4165 4165
    Length to face of fork(Without fork) mm 3100 3100 3100
    Overall Width mm 1600 1600 1600
    Overhead Guard Height mm 2255 2255 2255












    Application Area:

    1.Warehouse

    2.Port

    3.Factory

    4.Distribution Center

    5.Logistics



    If you have any other questions,please contact us directly.Our forklift are all with high quality,and you can choose any other engine to equip.It can be produced according to your idea.And we invite you to visit our factory





    Battery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse ForkliftBattery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse ForkliftBattery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse ForkliftBattery Fast Charged 4 Wheel Forklift , A Series Electric Warehouse Forklift



    We supply full range Forklift Trucks

    Diesel Forklift: 1.5ton, 2 ton, 2.5 ton, 3 ton, 3.5 ton, 4 ton, 4.5 ton, 5 ton, 6 ton, 7 ton, 7.5 ton, 8 ton, 10 ton

    Gasoline/Lpg Forklift: 1.5 ton, 1.8 ton, 2 ton, 2.5 ton, 3 ton, 3.5 ton, 4 ton, 4.5 ton, 5 ton, 6 ton, 7 ton

    Electric Forklift: 1 ton, 1.5 ton, 1.8 ton, 2 ton, 2.5 ton, 3 ton, 3.5 ton, 4 ton, 4.5 ton, 5 ton, 6 ton, 7 ton

    Heavy Duty Forklift: 12 ton, 13ton, 14ton, 15ton, 16ton, 18ton, 20ton, 25ton, 32ton, 46 ton

    Electric Stacker, Electric Pallet Truck

    Full-electric Stacker: Loading Capacity 1000kg, 1200kg, 1400kg, 1600kg, 2000kg

    Electric Pallet Truck: Loading Capacity 1500kg, 2000kg, 2800kg, 3000kg, 3500kg.
